The HAWK 400RS-IMP shares all functionality available on the 400RS such as working height of 400mm and throat depth of 200mm and can be optionally equipped with an automatic spindle. Simply push ‘’START’’ and the full process of lifting, clamping and testing takes place without operator interference.
The 400RS-IMP has an integrated Industrial PC, running Windows 10 and the INNOVATEST IMPRESSIONS™ MT workflow tester control software and a larger touchscreen with even more functionality. The system has all nowadays available connectivity such as LAN, WLAN, USB. Advanced tester operation and on screen guidance as well as remote service capabilities via INNOVATEST Team Viewer.
Scales: Rockwell, Superficial Rockwell (Brinell, Vickers optional)
Test forces: 1kgf-187.5kgf
3kgf, 10kgf pre-load, 15, 30, 45, 60, 100, 150kgf main load.
Brinell test forces from 1kgf-187.5kgf (optional).
Vickers test forces from 1kgf-150kgf (optional).
Knoop test forces from 1kgf-5kgf (optional).
Microscope: Brinell microscope package, for Brinell measurement (optional)
Load app. System: Fully automatic, Load cell, closed loop, force feedback. Absolute linear applied test force, no lever construction
Display: 8.5’’ industrial touchscreen
Software: IMPRESSIONS™ MT Software, workflow control, integrated industrial PC, Windows 10 licensed.
Output: USB, RJ45, WiFi
Illumination: Power LED near indenter for bright sample illumination
Spindle: Motorized spindle for fully automatic clamping & testing (optional)
Bottom Shell: Replaceable ABS covers avoids body damage
Workpiece Acc: 400mm (H) X 200mm (D)
